Water-Energy Nexus in the UAE

desalination-plant-uaeThe United Arab Emirates has been witnessing fast-paced economic growth as well as rapid increase in population during the last couple of decades. As a result, the need for water and energy has increased significantly and this trend is expected to continue into the future. Water in the UAE comes from four different sources – ground water (44%), desalinated seawater (42%), treated wastewater (14%), and surface water (1%). Most of the ground water and treated seawater are used for irrigation and landscaping while desalinated seawater is used for drinking, household, industrial, and commercial purposes.

Water consumption per capita in UAE is more than 500 liters per day which is amongst the highest worldwide. UAE is ranked 163 among 172 countries in the world in total renewable water resources (Wikipedia 2016). In short, UAE is expected to be amongst extremely water stressed countries in 2040 (World Resources Institute 2015).

To address this, utilities have built massive desalination plants and pipelines to treat and pump seawater over large distances. Desalinated water consumption in UAE increased from 199,230 MIG in 2003 to 373,483 MIG in 2013 (Ministry of Energy 2014). In 2008, 89% of desalinated seawater in UAE came from thermal desalination plants and most of them are installed at combined cycle electric power plants (Lattemann and Höpner 2008). Desalination is energy as well capital intensive process. Pumping desalinated seawater from desalination plants to cities is also an expensive proposition.

Electrical energy consumption in UAE doubled from 48,155 GWh in 2003 to 105,363 GWh in 2013. In 2013, UAE has the highest 10th electricity use per capita in the world (The World Bank 2014). Electricity in UAE is generated by fossil-fuel-fired thermoelectric power plants. Generation of electricity in that way requires large volumes of water to mine fossil fuels, to remove pollutants from power plants exhaust, generate steam that turns steam turbines, to cool down power plants, and flushing away residue after burning fossil fuels (IEEE Spectrum 2011).

Water production in UAE requires energy and energy generation in UAE requires water. So there is strong link between water and energy in UAE. The link between water and electricity production further complicates the water-energy supply in UAE, especially in winter when energy load drops significantly thus forcing power plants to work far from optimum points.

Several projects have been carried out in UAE to reduce water and energy intensity. Currently, the use of non-traditional water resources is limited to minor water reuse/recycling in UAE. Masdar Institute launched recently a new program to develop desalination technology that is powered by renewable energy (Masdar 2013).

Water-energy nexus in the UAE should be resilient and adaptive

Water-energy nexus in the UAE should be resilient and adaptive

Despite their interdependencies, water-energy nexus is not given due importance in the UAE. Currently, water systems in the UAE are vulnerable and not resilient to even small water and energy shortages. To solve this problem, water-energy nexus in UAE should be resilient and adaptive. Thus, there is a need to develop and demonstrate a new methodology that addresses water and energy use and supply in UAE cities in an integrated way leading to synergistic type benefits and improved water and energy security. Modern, cutting-edge science and engineering methods should be used with the goal of developing a robust framework that can identifying suitable future development scenarios, selection criteria and intervention options resulting in more reliable, resilient and sustainable water and energy use.

References

IEEE Spectrum. How Much Water Does It Take to Make Electricity? 2011. http://spectrum.ieee.org/energy/environment/how-much-water-does-it-take-to-make-electricity (accessed December 6, 2016).

Lattemann, Sabine, and Thomas Höpner. "Environmental impact and impact assessment of seawater desalination." Desalination, 2008: 1-15.

Masdar. Renewable Energy Desalination Pilot Programme. 2013. http://www.masdar.ae/en/energy/detail/renewable-energy-water-desalination-in-uae (accessed 12 7, 2016).

Ministry of Energy. Statistical Data for Electricity and Water 2013-2014. Abu Dhabi, 2014.

The World Bank. n.d. http://data.worldbank.org/country/united-arab-emirates?view=chart (accessed December 6, 2016).

The World Bank. Electric power consumption (kWh per capita). 2014. http://data.worldbank.org/indicator/EG.USE.ELEC.KH.PC?year_high_desc=true (accessed December 7, 2016).

Wikipedia. List of countries by total renewable water resources. 2016. https://en.wikipedia.org/wiki/List_of_countries_by_total_renewable_water_resources (accessed December 6, 2016).

World Resources Institute. Ranking the World’s Most Water-Stressed Countries in 2040. 2015. http://www.wri.org/blog/2015/08/ranking-world’s-most-water-stressed-countries-2040 (accessed December 6, 2016).

Republished by Blog Post Promoter

About Mohammed Abdallah

Mohammed Abdallah is a Water Control Engineer in Abu Dhabi Transmission and Dispatch Company (TRANSCO) since 2008. He hold bachelor’s degree in Mechanical Engineering from American University of Sharjah and master’s degree in Mechanical Engineering from Rochester Institute of Technology. His research interests are in water and energy management.
Tagged , , , , , , , , . Bookmark the permalink.

2 Responses to Water-Energy Nexus in the UAE

  1. Duncan Forbes says:

    Hi Mohammed, a great article highlighting the connection (nexus) between water and energy. I run programmes on teaching complex problem solving around the Water – Energy – Food Nexus for professionals and students.

    Reducing water intensity is crucial and too often the decision is made to introduce expensive technology through capital intensive ‘hard engineering’ projects as the solution. But this fails to address the issue that it is humans that are using all this water (energy and food). There needs to be much greater effort on ‘soft engineering’ solutions via customer education/public awareness programmes led by government, water and energy companies to encourage customer behaviour change – leading to energy and water saving behaviour. Also, stricter building regulations are needed to be enforced so that energy and water conservation measures are included in the design of any new building design project (aerated taps, solar hot water, grey water toilet flushing etc etc).

    Have a look at the lessons learnt in the recent droughts in Australia and South Africa. Australia went for panic buying of desalination plants – expensive and now possibly redundant. South Africa went for incentives/penalties aimed at water users and these proved (and remain) highly effective at reducing per head water consumption.

  2. Mohammed Alzaabi says:

    Thanks Mohammed for this interesting articale ,Thanks also to Mr. Duncan Forbes for his comments.I completly support the need to apply the WEF nexus approach ,I am working on my PhD thesis at Khalifa Unversity here at UAE to develope a WEF nexus &Governance frame work for UAE
